Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42" 48" Deck - for D100-D160, LA100-LA165, X110, X120
Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42" 48" Deck - for D100-D160, LA100-LA165, X110, X120 - Image 2
Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42" 48" Deck - for D100-D160, LA100-LA165, X110, X120 - Image 3
Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42" 48" Deck - for D100-D160, LA100-LA165, X110, X120 - Image 4

Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42″ 48″ Deck – for D100-D160, LA100-LA165, X110, X120

SKU LJG.03380 285-851,GX21694, GY20454, GY20867,GY20962,GY21098 Category Tags , , ,

Replaces 285-851 Spindle Assembly GY20962 GY21098 GY20454 42″ 48″ Deck – for D100-D160, LA100-LA165, X110, X120

Replaces OEM Part Numbers:GY20454,GY20867,GY20962,GY21098
Fits Models: X105,X110,X115R,X120,X125,X130R,X135R,X140,X145,X155R,X165
Fits Models: LA100,LA105,LA110,LA115,LA120,LA125,LA130,LA135,LA140,LA145,LA150,LA155,LA165
Fits Models: 92H,102,105,107H,107S,115,125,135,145,155C,190C,D100,D105,D110,D120,D125,D130,D140,D150,D155 D160
OD: 5″, Height: 7″,Includes Washer, nuts both ends, and grease fitting
285-851 Spindle Assembly GY20962 GY21098 GY20454 42″ 48″ Deck
Fits Models:: GY20454, GY20867, GY20962, GY21098
D100, D110, D130, D140, D150, D160, LA100, LA105, LA110, LA115, LA120, LA125, LA130, LA135, LA140, LA145, LA155, LA165
X105,X110,X115R,X120,X125,X130R,X135R,X140,X145,X155R,X165
: 82-359
285-851
TSB: 502-0039
Sunbelt: B1JD122
Thread: 9/16″-18 UNF5/8-18UNF
Includes grease zerk, pulley lock nut, blade lock nut, and washer
7 point star.Used on 42″, 48″ 54″ decks
